Sieger 70 TT Window
Slim, tilt and turn window
A contemporary aluminium window designed to provide a large, versatile tilt and turn opening with imperceptible handle and hinge options. These hidden elements are concealed within the sash to provide a pure aesthetic to the glazing design. The Sieger® 70 TT Window is fabricated in our Amersham fabrication facility and can be manufactured as part of a full glazing package. The elegant frames of this slim, tilt and turn window provides the perfect finishing touch to modern, rectilinear architectural designs.
Sightline: 66mm vent + frame profile
Max Sizes: up to 2.4m tall x 1.3m wide and 160kg per pane
Configurations: side hung, tilt&turn, bottom hung, tilt and turn parallel (all inward opening)
Weather Protection: air permeability class 4, wind resistance class C5, acoustic reduction RW 46 dB
Thermal Insulation: Uw value from 1.0 W/m2K
Typical Glass Spec: 6mm TXD outer, 16m argon filled cavity, 6mm TXD inner with low e coating
Frame Finishes: PPC, timber effect PPC, anodised and dual colour
The Sieger® 70 Window has been designed to meet some of the most complex industrial and architectural designs. Each Sieger® 70 window is manufactured bespoke to the measurements and requirements of each project for beautifully tailor-made fenestration.
The beauty of this system is the large openings and minimalistic aesthetic achievable with this design. The handle, hinges and locking mechanism are all hidden within the frame of this large tilt and turn window to enhance the modernity of the building envelope. The vent and frame profiles are just 66mm, which results in a highly glazed facade due to the minimal visible framing.
The slim design of this window works perfectly with the slim aluminium door systems available from Sieger®, including the Sieger® Slim Sliding Door and the Sieger® Lux Bifold. Specifying various Sieger® Systems within your bespoke glazing package will ensure a cohesive design to your project.
Speak to a member of the Sieger® team who will be able to show you the Sieger® 70 Window in person and offer your advice to help materialise your ideas. To arrange a showroom visit email [email protected] or call us on 01494 722 882.
